Nalophan bags are commonly used for air sampling and especially for odour analysis. Even if olfactometric measurement must be carried out within maximum 30 hours after sampling, the question of potential sample evolution is always present. This study illustrates the behaviour of selected sulphur compounds in Nalophan bags from filling to analysis (over a period up to 100 hours).

   Select compounds were hydrogen sulphide, carbon disulphide, methyl mercaptan, ethyl mercaptan, dimethyl sulphide, diethyl sulphide and dimethyl disulphide and tested at high concentration level (in a range of 3900 to 1800 ppb each) to facilitate their direct and quick measurement by gas chromatography with flame photometric detector. The chemical analysis shows losses by adsorption and by diffusion depending on time and other conditions. Even if the variation seems limited during the first hours, the evolution shows that the need for a better film is real.

    This work aims to describe the Italian pilot study carried out within the frame of the H2020 D-NOSES project and discuss the opportunity to integrate different approaches in order to deal with complex situations. The pilot study was carried out in the municipal area between Castellanza, Marnate, and Olgiate Olona, where an odour problem has been lamented for years.

    As a first step of the project, 4 industries were identified as potential odour sources: a chemical plant, the municipal WWTP, a textile and dyeing industry, and the WWTP connected to the dyeing industry. In order to monitor the odour problem, it was proposed to combine the application of the D-NOSES methodology with the “traditional” way involving olfactometric measurements and dispersion modelling, the latter being the approach foreseen by the Regional guideline. The comparison of the citizens’ observations and the model outcomes allowed to verify the compatibility of the odour observations with the emissions from the two WWTPs.

   Determining the emission impact of area sources (biofilters, wastewater tanks) on air quality and the environment by classic measurement techniques (i.e. static hood sampling), is currently lacking in pertaining uniform and representative emission data by being restricted in sampling area, time and safety. This creates an extra hindrance when emission rates from such sources need to be determined by the fluxwindow method, which implies measuring emission concentrations up- and downwind along different horizontal and vertical profiles of the area source.

   In an effort to improve on this matter, the possibility of using a drone equipped with an emission detection laboratory (OLFASCAN Flying Lab) to quantify emission concentrations and rates via the fluxwindow method from a sludge buffer tank was investigated. The OLFASCAN Flying Lab is equipped with several electrochemical sensors for performing air quality measurements and was attached to a DJI Matrice600 PRO RTK drone.
